WALL sandwich panels with polyurethane foam core

The system of sandwich panels with a core of rigid polyurethane foam type PIRTECH in metal cladding includes:

  • wall plates with visible fixing – STANDARD
  • wall plates with concealed fixing – PLUS
  • refrigeration panels – refrigeration
  • roof panels – ROOF

Technical data

WALL PROFILE WALL sandwich panels with polyurethane foam core WALL sandwich panels with polyurethane foam core WALL sandwich panels with polyurethane foam core
name PIRTECH STANDARD PIRTECH PLUS PIRTECH REFRIGERATION
designation PWS-PIR-ST PWS-PIR-PL PWS-PIR-CH
filling polyurethane – PIR
thickness 40, 50*, 60, 80, 100,110,120 mm 60, 80, 100, 120 mm, 120, 140, 160, 180, 200, 220 mm
effective width 1000, 1100, 1150 mm 1000, 1150 mm 1000, 1100, 1150 mm
thickness of sheet metal inside/outside 0.5 / 0.4 mm
on request 0.4 – 0.7 / 0.4 – 0.63 mm
type of external profiling trapezoid – T, microtrapezoid – M, wave – F, cassette – K, flat – P
type of internal profiling trapezoid – T
protective coatings PS, polyurethane, HPS200

*inquire about availability
