| [mm] | |
| feed width | 1000/1500 |
| sheet thickness | 0.7 to 1.50 |
| coverage width | 634/950 |
| overall width | 684/1000 |
| recommended length max. | 12,000/14,000 mm |
| * in option with anti-condensation felt. | |
Polyester gloss 15 µm
Metallic coatings
OC- galvanized
NOTE:
The presented sheet metal colors may differ from the actual colors due to differences between graphics cards and monitors.
| protective coatings | coating thickness |
| polyester gloss | 15 and 25 µm |
| OC- galvanized | 200,275 g/m² |
