| Module length [mm] | 350 or 400 |
| Embossing height [mm] | 15 or 20 |
| Profile height [mm] | 20 |
| usable width [mm] | 1150 |
| total width [mm] | 1206 |
| Sheet length [mm] for module 350 | min.800/max.5000 |
| Sheet length [mm] for module 400 | min.900/max 5300 |
| min. slope: | 9° |
ULTRAMAT 35 µm
Poliester połysk 25 µm
Poliester mat gruboziarnisty 35 µm*
* dostępność kolorów w powłoce poliester matowy gruboziarnisty do potwierdzenia
Powłoka hybrydowa - PURMAX®40 µm
Poliuretan - PURLAK®50 µm
Poliuretan - PURMAT®50 µm
Kolory specjalne
UWAGA:
Zaprezentowane kolory blach mogą różnić się od kolorów rzeczywistych w związku z występowaniem różnic pomiędzy kartami graficznymi oraz monitorami.
| coatings security | thickness coatings | warranty |
| PURMAT ® | 50 µm | 30/50 years |
| PURLAK ® | 50 µm | 30/50 years |
| PURMAX ® | 40 µm | 20/40 years |
| ULTRAMAT | 35 µm | 15/35 years |
| coarse matte polyester* | 35 µm | 15/35 years |
| polyester gloss | 25 µm | 10/30 years |
* color availability in coarse matte polyester coating to be confirmed.
Examples of realizations
